DL25M Slant Bed CNC Lathe
The DL-25M is a fully functional CNC lathe manufactured by our company, featuring two-coordinate control, two-axis simultaneous movement, and semi-closed loop control. Its monoblock cast bed with a 45° inclined guideway layout ensures high rigidity and machining stability.
| Max. swing diameter over bed | Φ520mm |
| Max .turning length | 1000/1500mm |
| Guideway type | Box way |
| Chuck size | 10 |
| Spindle motor power | 15/18.5kw |
| Spindle speed range | 3500rpm |
| Spindle bore | Φ87mm |
| Max Cross travel of X axis | 260mm |
| Max Cross travel of Z axis | 1040/1600 |
DL25M
The structure and machining accuracy of key precision-related components including the bed, carriage, lead screw, and supports have been meticulously optimized. Through strengthened assembly control protocols, overall machine accuracy and reliability have been significantly improved, with repeat positioning accuracy enhanced by 30%.
